Product Description

What is Electronic parking brake？

An electronic parking brake (EPB), also known as an electric park brake in North America, is an electronically controlled parking brake, whereby the driver activates the holding mechanism with a button and the brake pads are electrically applied to the rear wheels.  This is accomplished by an electronic control unit (ECU) and an actuator mechanism.  There are two mechanisms that are currently in production, Cable puller systems and Caliper integrated systems.  EPB systems can be considered a subset of Brake-by-wire technology.

Functionality

Apart from performing the basic vehicle holding function required of park brakes, the EPB systems provide other functions like automatic release of the park brakes when the driver presses the accelerator or slips the clutch, and re-clamping using additional force on detection of vehicle motion. Further, the hill-hold function, which applies brakes to prevent roll-back when pulling away on a gradient, can also be implemented using the EPB.

OE Number

8W0998281	8W0615403MQC8	8W0615403
8W0615404A	8W0615403M	80A615403DSL7
8W0615404	8W0615403H	80A615403D
8W0615403NSL7	8W0615403G	80A615403A
8W0615403MSL7	8W0615403A	32355763

Compatible Applications

AUDI Q5 Quattro Sportback 50 TFSi e/55 TFSi e (FYT) Sports Utility Vehicle 2.0 Q 2/2021 - -

AUDI A5 Sportback TFSi (F5A, F5F) Hatchback 1.4 B 1/2017 - 2/2020

AUDI A5 Sportback TFSi (F5A, F5F) Hatchback 2.0 B 1/2017 - 2/2020

AUDI S5 Cabrio Quattro TFSi (F57, F5E) Cabriolet 3.0 B 11/2016 - -

AUDI A5 Quattro TDi (F53, F5P) Coupe 3.0 D 2/2017 - 12/2017

AUDI A5 Sportback TFSi Mild Hybrid (F5A, F5F) Hatchback 2.0 J 5/2017 - 2/2020

AUDI A5 TFSi Mild Hybrid (F53, F5P) Coupe 2.0 J 5/2017 - 2/2020

AUDI A5 Sportback Quattro TFSi Mild Hybrid (F5A, F5F) Hatchback 2.0 J 5/2017 - 2/2020

AUDI A5 Sportback Quattro TDi (F5A, F5F) Hatchback 3.0 D 2/2017 - 12/2017

AUDI A5 Quattro TFSi Mild Hybrid (F53, F5P) Coupe 2.0 J 5/2017 - 2/2020

AUDI S4 Quattro TDi Mild Hybrid (8W2, 8WC) Saloon 3.0 I 12/2018 - -

AUDI A4 35 TDi/TDi (8W5, 8WD) Estate 2.0 D 8/2015 - 10/2019

AUDI A4 TDi (8W5, 8WD) Estate 3.0 D 10/2015 - 8/2018

AUDI Q5 Quattro 45 TFSi Mild Hybrid (FYB, FYG) Sports Utility Vehicle 2.0 J 8/2018 - -

AUDI A4 TFSi (8W2, 8WC) Saloon 2.0 B 11/2015 - 11/2019

AUDI A4 TDi (8W2, 8WC) Saloon 2.0 D 5/2015 - 11/2019

AUDI A5 TFSi (F53, F5P) Coupe 1.4 B 11/2016 - 2/2020

AUDI A5 35 TDi/TDi (F53, F5P) Coupe 2.0 D 5/2017 - 2/2020

AUDI A4 Quattro TFSi (8W5, 8WD) Estate 2.0 B 11/2015 - 10/2019

AUDI A5 Sportback 35 TDi/TDi (F5A, F5F) Hatchback 2.0 D 1/2017 - 2/2020

AUDI S5 Quattro TDi Mild Hybrid (F53, F5P) Coupe 3.0 I 12/2018 - -

AUDI A5 Sportback Quattro TFSi (F5A, F5F) Hatchback 2.0 B 9/2016 - 2/2020

AUDI A5 Sportback TFSi (F5A, F5F) Hatchback 2.0 B 11/2016 - 2/2020

AUDI A6 Allroad Quattro 55 TDi Mild Hybrid (4AH) Estate 3.0 I 3/2019 - -

AUDI S5 Sportback Quattro TDi Mild Hybrid (F5A, F5F) Hatchback 3.0 I 12/2018 - -

AUDI A4 TFSi (8W5, 8WD) Estate 2.0 B 5/2016 - 10/2019

AUDI A7 Sportback Quattro 50 TFSi e (4KA) Hatchback 2.0 Q 7/2019 - -
